Natural Gas Gensets Powered By Yuchai Gas Engines

Gas Gensets Powered By Yuchai Gas Engines

50Hz/60Hz
Optional Alternators: Leroy Somer, Stamford, Evotec, Engga
Optional Controllers: ComAP, Deepsea, DEIF, SmartGen
Optional Configurations:
ATS Panel, Synchronization Panel
CHP Heat Recovery System
Biogas Scrubber
Compact Soundproof Canopy/ 20ft/40ft Containerized Canopy

INQUIRY Whatsapp

Product Details

Product Tags

Product Descriptions:

1. Engine components tailored for gas internal combustion, enhancing overall reliability.

2. Integrated water outlet pipe design in cylinder head for improved sealing reliability.

3. Utilization of advanced turbocharging technology ensures efficient air intake for optimal combustion and reduced emissions.

4. Excellent transient speed regulation and robust loading capacity, meeting generator set performance demands effectively.

Product Overviews:

Natural Gas Gensets Powered By Yuchai Gas Engines

Natural Gas Genset Model	Continuous Power	Engine Model	Number Of Cylinders	Displacement	Compression Ratio	Exhaust Temp.	Electrical Efficiency
U1Y180-G	180KW	YC6MK315N-D30	6	10.34L	11.5:1	<550℃	35%
U1Y220-G	220KW	YC6K350N-D30	6	12.94L	11.5:1	<550℃	34%
U1Y250-G	250KW	YC6K420N-D30	6	12.94L	11.5:1	<540℃	35%
U1Y350-G	350KW	YC6TD600N-D31	6	19.6L	11.5:1	<500℃	37%
U1Y400-G	400KW	YC6C750N-D30	6	39.85L	11:1	<500℃	35%
U1Y500-G	500KW	YC6C935N-D30	6	39.85L	11:1	<500℃	36%
U1Y600-G	600KW	YC6C1020N-D30	6	39.85L	11:1	<500℃	36%
U1Y800-G	800KW	YC12VTD1350N-D30	12	39.2L	12.5:1	<500℃	35%
U1Y1000-G	1000KW	YC12YC1680N-D31	12	79.17L	11.5:1	<500℃	37%
