50Hz Diesel Gensets Powered By Cummins CCEC

Optional Alternators: Leroy Somer, Stamford, Evotec, Engga
Optional Controllers: ComAP, Deepsea, DEIF, SmartGen
Optional Configurations:
ATS Panel, Synchronization Panel
CHP Heat Recovery System
Compact Soundproof Canopy, 20ft/40ft Containerized Canopy

INQUIRY Whatsapp

Product Details

Product Tags

This series of generator sets is powered by Cummins engines from Chongqing Cummins Engine Co., Ltd. (CCEC)

50Hz Diesel Gensets Powered By Chongqing Cummins

Product Overviews:

Diesel Gensets Powered By Chongqing Cummins

Frequency	Genset Model	Prime Power kva/kw	Standby Power kva/kw	Engine Model	Fuel Consumption L/h	Cylinder	Displacement (L)
50Hz	U1GC220S-I	250/200	275/220	NT855-GA	53.0	6L	10.8
50Hz	U1GC220S-II	250/200	275/220	MTA11-G2	52.0	6L	10.8
50Hz	U1GC220S-III	250/200	275/220	NTA855-G1	59.0	6L	14.0
50Hz	U1GC220S-IV	250/200	275/220	QSNT-G6	62.0	6L	14.0
50Hz	U1GC250S-I	275/220	313/250	QSNT-G7	68.0	6L	14.0
50Hz	U1GC250S-II	275/220	313/250	NTA855-G1A	61.0	6L	14.0
50Hz	U1GC280S-I	313/250	350/280	MTAA11-G3	61.3	6L	14.0
50Hz	U1GC280S-II	313/250	350/280	NTA855-G1B	68.0	6L	14.0
50Hz	U1GC280S-III	313/250	350/280	NTA855-G2	68.0	6L	14.0
50Hz	U1GC280S-IV	313/250	350/280	QSNT-G1	76.0	6L	14.0
50Hz	U1GC300S	344/275	375/300	NTA855-G2A	72.0	6L	14.0
50Hz	U1GC310S-I	350/280	388/310	NTA855-G4	75.0	6L	14.0
50Hz	U1GC310S-II	350/280	388/310	QSNT-G2	80.0	6L	18.9
50Hz	U1GC330S-I	365/300	413/330	NTAA855-G7	86.0	6L	14.0
50Hz	U1GC330S-II	365/300	413/330	KTA19-G2	83.0	6L	19.0
50Hz	U1GC350S	400/320	438/350	QSNT-G3	70.5	6L	18.9
50Hz	U1GC360S	N/A	450/360	NTAA855-G7A	98.0	6L	18.9
50Hz	U1GC400S-I	450/360	500/400	QSNT-G4X	80.0	6L	18.9
50Hz	U1GC400S-II	450/360	500/400	QSK19-G14	99.7	6L	18.9
50Hz	U1GC400S-III	450/360	500/400	KTA19-G3	97.0	6L	18.9
50Hz	U1GC450S-I	500/400	562/450	KTA19-G3A	106.9	6L	18.9
50Hz	U1GC450S-II	500/400	562/450	KTA19-G4	107.0	6L	18.9
50Hz	U1GC450S-III	500/400	562/450	QSK19-G13	109.5	6L	19.0
50Hz	U1GC505S-I	575/460	630/505	QSK19-G12	128.3	6L	19.0
50Hz	U1GC505S-II	525/420	630/505	KTAA19-G5	113.0	6L	19.0
50Hz	U1GC517	588/470	646/517	QSK19-G6	129.6	6L	19.0
50Hz	U1GC520S-I	575/460	650/520	KTAA19-G6	118.5	6L	19.0
50Hz	U1GC520S-II	N/A	650/520	KTA19-G8	141.4	6L	19.0
50Hz	U1GC550S-I	N/A	688/550	KTAA19-G6A	155.0	6L	19.0
50Hz	U1GC550S-II	N/A	688/550	KTAA19-G7	155.0	6L	19.0
50Hz	U1GC560S	625/500	700/560	KT38-G	140.0	12V	37.8
50Hz	U1GC570S	650/520	712/570	QSK19-G4	143.0	12V	19.0
50Hz	U1GC600S	688/550	750/600	QSK19-G11	153.8	12V	19.0
50Hz	U1GC630S-I	712/570	788/630	KTA38-G1	160.4	12V	38.0
50Hz	U1GC630S-II	712/570	788/630	KTA38-G1B	160.4	12V	38.0
50Hz	U1GC640S	725/580	800/640	KTA38-GA	168.2	12V	38.0
50Hz	U1GC660S-I	750/600	825/660	KTA38-G2	167.0	12V	38.0
50Hz	U1GC660S-II	750/600	825/660	QSK38-G8	168.0	12V	38.0
50Hz	U1GC710S-I	800/640	888/710	KTA38-G2B	167.3	12V	38.0
50Hz	U1GC710S-II	813/650	888/710	QSK38-G7	180.0	12V	38.0
50Hz	U1GC800S-I	910/728	1000/800	KTA38-G2A	191.0	12V	38.0
50Hz	U1GC800S-II	910/728	1000/800	QSK38-G6	197.0	12V	38.0
50Hz	U1GC880S	1000/800	1100/880	KTA38-G5	209.0	12V	38.0
50Hz	U1GC887S	1000/806	1108/887	QSK38-G1	212.0	12V	38.0
50Hz	U1GC1000S	N/A	1250/1000	KTA38-G9	247.5	12V	38.0
50Hz	U1GC1007S	1144/915	1258/1007	QSK38-G2	235.0	12V	38.0
50Hz	U1GC1100S-I	1250/1000	1375/1100	QSK38-G5	271.0	12V	38.0
50Hz	U1GC1100S-II	1250/1000	1375/1100	KTA50-G3	254.0	16V	50.3
50Hz	U1GC1100S-III	1250/1020	1375/1100	KTA50-G12	249.0	16V	50.3
50Hz	U1GC1320S-I	1375/1100	1650/1320	KTA50-G8	289.0	16V	50.3
50Hz	U1GC1320S-II	1375/1100	1650/1320	QSK38-G19	288.0	12V	38.0
50Hz	U1GC1280S	1375/1100	1600/1280	KTA50-G12A	207	16V	50.3
50Hz	U1GC1320S	1500/1200	1650/1320	KTA50-GS8	308.8	16V	50.3
50Hz	U1GC1360S	1540/1232	1700/1360	QSK50-G4	338	16V	50.3
50Hz	U1GC1460S	1650/1320	1825/1460	QSK50-G7	349	16V	50.3
